LUMEN HARU
Fabrication Kit
3-in-1
Electrode, cutting disc and grinding disc together — a complete weld-and-finish workflow in one order.
From $1.93Request a quote
AWS A5.1EN 12413EN 13236ISO 9001:2015DNV·GLSGS · RoHS · CEAWS A5.1EN 12413EN 13236ISO 9001:2015DNV·GLSGS · RoHS · CE
Tensile ≥490 MPaImpact ≥27 J @ −30°CDiffusible H ≤4 ml/100 g
Main photo
A low-hydrogen, high-strength electrode for welds that demand strength, impact toughness and resistance to cold cracking. Suited to projects with welding procedures (WPS), quality control and acceptance documentation — heavy structures, pressure vessels, bridges, and oil and gas.
Welding — Electrodes, MIG/MAG & flux-cored wire
Sizes & ordering
| SKU | Size | Price |
|---|---|---|
| HAK-E7018-2.5X300 | 2.5×300mm | $1.51 |
| HAK-E7018-3.2X350 | 3.2×350mm | $1.41 |
| HAK-E7018-4.0X400 | 4.0×400mm | $1.41 |
| HAK-E7018-5.0X400 | 5.0×400mm | $1.41 |
Applications
- Heavy steel structures — beams, columns, trusses
- Heavy transport and chassis
- Pipelines and pressure or oil tanks
- Heavy construction and mining machinery
- Shipbuilding and port equipment
- Heavy industrial equipment bases
Notes & safetyLow-hydrogen: must bake 350°C × 2h and hold in a 100–150°C quiver; re-bake if exposed over 4h. Diffusible hydrogen ≤4 ml/100 g. Mechanical: tensile ≥490 MPa, yield ≥400 MPa, elongation ≥22%, impact ≥27 J at −30°C. Recommended current — 2.5mm 70–100A · 3.2mm 110–150A · 4.0mm 150–200A · 5.0mm 200–260A.
Combos — order together
Electrode Pair
2-in-1
Both electrode grades — general-purpose E6013 and low-hydrogen E7018 — for everyday and structural work.
From $2.51Request a quote
