LUMEN HARU
Fabrication Kit
3-in-1
Electrode, cutting disc and grinding disc together — a complete weld-and-finish workflow in one order.
From $1.93Request a quote
AWS A5.1EN 12413EN 13236ISO 9001:2015DNV·GLSGS · RoHS · CEAWS A5.1EN 12413EN 13236ISO 9001:2015DNV·GLSGS · RoHS · CE
AWS A5.1 certified70–230 A · AC/DCAll positions · F·H·V·OH
Main photo
An easy-to-run, general-purpose carbon-steel electrode prized for arc stability, operator handling and flexibility across job-site conditions. Ideal for everyday welding in light fabrication and repair — thin sheet and ordinary steel structures up to about 16 mm. For pressure vessels, bridges and heavy load-bearing work, use E7018 instead.
Welding — Electrodes, MIG/MAG & flux-cored wire
Sizes & ordering
| SKU | Size | Price |
|---|---|---|
| KT-E6013-2.5X300 | 2.5×300mm | $1.17 |
| KT-E6013-3.2X350 | 3.2×350mm | $1.10 |
| KT-E6013-4.0X400 | 4.0×400mm | $1.10 |
| KT-E6013-5.0X400 | 5.0×400mm | $1.10 |
Applications
- Gates, fences, railings, shelves and gussets
- Light vehicles, trailers and frame reinforcement
- Light ships and low-pressure pipe
- Agricultural machinery
- Temporary and light structural steel
- General repair — machine frames, conveyors, pump bases
Notes & safetyEasy arc start; neat welds on clean or lightly rusted steel, stable even on low-voltage AC. Mechanical: tensile ≥430 MPa, yield ≥330 MPa, elongation ≥17%. Recommended current — 2.5mm 70–110A · 3.2mm 100–140A · 4.0mm 140–180A · 5.0mm 180–230A. Store dry; bake 80–100°C for 1h if damp.
Combos — order together
Electrode Pair
2-in-1
Both electrode grades — general-purpose E6013 and low-hydrogen E7018 — for everyday and structural work.
From $2.51Request a quote
